- Model
- Mass-Slide rail (g)
- Mass - Cylindrical rollers with cage(g)
- A(mm)
- H(mm)
- L(n×F)
- E(mm)
- Dw(mm)
- R(mm)
- Z
- p(mm)
- e(mm)
- W(mm)
- g(mm)
- M
- d1(mm)
- d2(mm)
- h(mm)
- t(mm)
- Maximum Stroke Length(mm)
- Basic Dynamic Load Rating C(N)
- Basic Static Load Rating C0(N)
- Allowable Load F(N)
VRG 2- 30
6.53
0.38
12
6
30(1×15)
7.5
2
25.6
4
4
2.8
5.5
2.5
M3
2.55
4.4
2
1.5
9
913
1180
392
VRG 2- 45
9.53
0.72
12
6
45(2×15)
7.5
2
41.6
8
4
2.8
5.5
2.5
M3
2.55
4.4
2
1.5
7
1570
2350
783
VRG 2- 60
12.5
0.88
12
6
60(3×15)
7.5
2
49.6
10
4
2.8
5.5
2.5
M3
2.55
4.4
2
1.5
21
1860
2940
979
VRG 2- 75
15.5
1.22
12
6
75(4×15)
7.5
2
65.6
14
4
2.8
5.5
2.5
M3
2.55
4.4
2
1.5
19
2420
4110
1370
VRG 2- 90
18.5
1.39
12
6
90(5×15)
7.5
2
73.6
16
4
2.8
5.5
2.5
M3
2.55
4.4
2
1.5
33
2680
4700
1570
VRG 2-105
21.5
1.72
12
6
105(6×15)
7.5
2
89.6
20
4
2.8
5.5
2.5
M3
2.55
4.4
2
1.5
31
3190
5880
1960
VRG 2-120
24.5
1.89
12
6
120(7×15)
7.5
2
97.6
22
4
2.8
5.5
2.5
M3
2.55
4.4
2
1.5
45
3440
6460
2150
VRG 2-135
27.5
2.22
12
6
135(8×15)
7.5
2
113.6
26
4
2.8
5.5
2.5
M3
2.55
4.4
2
1.5
43
3910
7640
2550
VRG 2-150
30.5
2.39
12
6
150(9×15)
7.5
2
121.6
28
4
2.8
5.5
2.5
M3
2.55
4.4
2
1.5
57
4150
8230
2740
VRG 3- 50
22.8
1.69
18
8
50(1×25)
12.5
3
42
6
5
3.5
8.3
3.5
M4
3.3
6
3.1
2
13
2740
3660
1220
VRG 3- 75
33.3
2.71
18
8
75(2×25)
12.5
3
62
10
5
3.5
8.3
3.5
M4
3.3
6
3.1
2
23
4080
6090
2030
VRG 3-100
43.8
3.72
18
8
100(3×25)
12.5
3
82
14
5
3.5
8.3
3.5
M4
3.3
6
3.1
2
33
5300
8530
2840
VRG 3-125
54.4
4.74
18
8
125(4×25)
12.5
3
102
18
5
3.5
8.3
3.5
M4
3.3
6
3.1
2
43
6440
11000
3660
VRG 3-150
64.9
5.75
18
8
150(5×25)
12.5
3
122
22
5
3.5
8.3
3.5
M4
3.3
6
3.1
2
53
7530
13400
4470
VRG 3-175
75.4
6.77
18
8
175(6×25)
12.5
3
142
26
5
3.5
8.3
3.5
M4
3.3
6
3.1
2
63
8570
15800
5280
VRG 3-200
85.9
7.78
18
8
200(7×25)
12.5
3
162
30
5
3.5
8.3
3.5
M4
3.3
6
3.1
2
73
9580
18300
6090
VRG 3-225
96.4
8.8
18
8
225(8×25)
12.5
3
182
34
5
3.5
8.3
3.5
M4
3.3
6
3.1
2
83
10600
20700
6910
VRG 3-250
107
9.81
18
8
250(9×25)
12.5
3
202
38
5
3.5
8.3
3.5
M4
3.3
6
3.1
2
93
11500
23200
7720
VRG 4- 80
59.6
9.7
22
11
80(1×40)
20
4
73
8
7
5
10
4.5
M5
4.3
7.5
4.1
2
14
6690
9400
3130
VRG 4-120
88
12
22
11
120(2×40)
20
4
101
12
7
5
10
4.5
M5
4.3
7.5
4.1
2
38
9180
14100
4700
VRG 4-160
116
14.3
22
11
160(3×40)
20
4
129
16
7
5
10
4.5
M5
4.3
7.5
4.1
2
62
11500
18800
6270
VRG 4-200
145
16.7
22
11
200(4×40)
20
4
157
20
7
5
10
4.5
M5
4.3
7.5
4.1
2
86
13700
23500
7830
VRG 4-240
173
20.1
22
11
240(5×40)
20
4
199
26
7
5
10
4.5
M5
4.3
7.5
4.1
2
82
16700
30600
10200
VRG 4-280
201
22.5
22
11
280(6×40)
20
4
227
30
7
5
10
4.5
M5
4.3
7.5
4.1
2
106
18700
35300
11800
VRG 4-320
230
24.8
22
11
320(7×40)
20
4
255
34
7
5
10
4.5
M5
4.3
7.5
4.1
2
130
20600
40000
13300
VRG 6-100
147
12
31
15
100(1×50)
25
6
75
6
9
6
14
6
M6
5.3
9.5
5.2
3
48
11200
13800
4610
VRG 6-150
216
22.6
31
15
150(2×50)
25
6
129
12
9
6
14
6
M6
5.3
9.5
5.2
3
40
19300
27700
9230
VRG 6-200
285
29.7
31
15
200(3×50)
25
6
165
16
9
6
14
6
M6
5.3
9.5
5.2
3
68
24100
36900
12300
VRG 6-250
353
36.8
31
15
250(4×50)
25
6
201
20
9
6
14
6
M6
5.3
9.5
5.2
3
96
28700
46100
15400
VRG 6-300
422
43.9
31
15
300(5×50)
25
6
237
24
9
6
14
6
M6
5.3
9.5
5.2
3
124
33000
55400
18500
VRG 6-350
491
51
31
15
350(6×50)
25
6
273
28
9
6
14
6
M6
5.3
9.5
5.2
3
150
37200
64600
21500
